Plunger Dispensing Valve

Plunger Dispensing Valve is an aluminum valve designed for controlled dispensing of low-viscosity, particle-free liquids such as UV adhesives and epoxy, with simple single-action operation.

PREV：Low-Flow Dispensing Valve NEXT：Snuff-Back Dispensing Valve

Product Parameters
Core Advantages
Application Scenarios
OEM / ODM Services
FAQs

Product Model	VSD-070
Product Type	Plunger Dispensing Valve
Main Material	Aluminum
Work Pressure	4–6 bar
Inlet Pressure	1–100 bar
Minimum Dispensing	0.1 ml
Applicable Viscosity	<30,000 cP
Inlet Size	1/8" NPT (F)
Operating Frequency	<300 points/min
Dimensions	120 × 25 mm
Control	Single Action
Compatible Equipment	VS-982 / VS-983
MOQ	5 pcs
Lead Time	3–7 days
Samples	Available


Designed for Low-Viscosity Liquids The Plunger Dispensing Valve is designed for particle-free liquids with viscosities below 30,000 cP, making it suitable for controlled dispensing of UV adhesives, epoxy, and similar materials.	Simple Single-Action Control The valve uses single-action pneumatic control. When air is supplied, the valve opens; when the air supply is disconnected, the valve closes, providing straightforward operation for automated dispensing equipment.	Mild Suction Function A mild suction function helps reduce residual material flow after dispensing, supporting cleaner stopping performance during repeated adhesive application.	Controlled Dispensing Volume With a minimum dispensing amount of 0.1 ml and an operating frequency of up to 300 points/min, the adhesive dispensing valves can support repeated dispensing processes requiring controlled material output.


UV Adhesive Dispensing The adhesive dispensing valves can be used for controlled application of UV adhesives in assembly and manufacturing processes.	Epoxy Dispensing The valve supports dispensing of suitable low-viscosity epoxy materials where consistent material delivery is required.	Precision Liquid Dispensing With a minimum dispensing amount of 0.1 ml, the Plunger Dispensing Valve is suitable for applications requiring controlled delivery of small amounts of liquid.	Automated Dispensing Equipment The single-action pneumatic design allows the valve to be integrated into automated systems for repeated dispensing operations.


Equipment Integration We can support integration of the valve with compatible dispensing machines and customer-specified material supply systems.	Application-Based Configuration Our team can recommend suitable valve configurations according to material viscosity, dispensing volume, and production requirements.	Pneumatic System Matching The valve can be configured for dispensing equipment using a 1/8" NPT inlet and a working pressure of 4–6 bar.

1. What is the Plunger Dispensing Valve used for?
The Plunger Dispensing Valve VSD-070 is designed for controlled dispensing of low-viscosity, particle-free liquids, including UV adhesives and suitable epoxy materials.

2. What viscosity range can the Plunger Dispensing Valve handle?
The valve is designed for materials with viscosities below 30,000 cP.

3. What is the MOQ for the adhesive dispensing valves?
The MOQ is 5 pieces, allowing customers to order small quantities for equipment testing or initial evaluation.

4. What is the standard lead time?
The standard lead time is 3–7 days, depending on order quantity and product configuration.

5. Are samples available before bulk orders?
Yes. Samples are available for customers who need to test the valve with their own materials and dispensing equipment.

Recommended Products

Customized to Your Specifications

We not only offer standard products but also possess strong OEM/ODM and engineering customization capabilities. Customers can provide:
● Product drawings
● Physical samples
● Equipment model
● Adhesive type
● Mixing ratio
● Capacity requirements
● Interface dimensions
Our engineering team can assist in product selection and structural matching based on actual applications. This allows us to help customers reduce procurement risks caused by size mismatches, interface incompatibility, insufficient mixing effects, or poor user experience.
